solar storage power station, ups 32700 LiFePO4 lithium battery 12v 25ah
| tem | General Parameter | Remarks |
| Material | Lithium Iron Phosphate | |
| Single Cell Model | IFR-32650-3.2V-5Ah | |
| Rated Voltage | 12.8V | Working Voltage-3.2V |
| Max.Charge Voltage | 14.6V | Single Ave. Charge Voltage-3.65V |
| Cut-off Voltage | 10V | Single Ave. Discharge Voltage-2.5V |
| Rated Capacit1 | 25Ah | |
| Standard Charge Current | 5A | 0.2C |
| Max. Charge Current | 25A | 1C |
| Fast Charging Time | 1h | |
| Max. Constinuous Discharge Current | 25A | 1C |
| Peak Discharge Current | 50A | 2C |
| Dimension | customized | |
| Weight | 4Kg | |
| Package | steel case | |
| BMS Included | Yes | |
| Cycle Life | over 2000 times | with 1C charge and discharge current and 25 ℃ temparature, 80%DOD |
| Charge Temperature | 0-45 ℃ | |
| Discharge Temperature | -20-65 ℃ | |
| Storage Temperature | -20-45 ℃ | |
Features
Excellent high and low temperature discharge performance . Nominal voltage 3.2V, 90% capacity output under the stable voltage
Widely using temperature range, can be operated in -40°C~+60°C.
Excellent storage life and reliability. With low self-discharge, selft-discharge rate≤5% monthly.
Flexible design,also can make special design for customers.
Long cycle life, more than 2000 charge/discharge cycles ( 80% capacity remained ).
lithium batteries are environmentally friendly and pollutant free power, it's without mercury, cadmium,lead and other heavy metals.
Application
Digital Products : Bluetooth, MP3,MP4,P-DVD, Cellular Phone.
Portable Electronics: Notebook Computers, LCD light, Digital Camera, Emergency Lighting
Backup power supply, Medical Device,Electric nipper .
Electric bicycles, HEV, EV.
Medical instruments.
solar storage power station, ups, backup emergency battery etc.
ut mercury, cadmium,lead and other heavy metals.
