76.8Wh Energy Lifepo4 Lithium Ion Battery FT-32LFP-12.8V6AH Free Maintenance

Product Categories

FORZATEC CO., LIMITED

Contact Now

Name: 768Wh Energy Lifepo4 Lithium Ion Battery FT32LFP128V6AH Free Maintenance
Brand: FORZATEC
Price: 1 USD

Brand Name : FORZATEC

Model Number : FT-32LFP-12.8V6AH

Certification : CE&ROHS

Place of Origin : CHINA

MOQ : 100

Payment Terms : L/C, T/T

Supply Ability : 10,000 PER MONTHS

Delivery Time : 15 DAYS

Packaging Details : CARTON AND PALLETS

Nominal Voltage : 12.8V

Nominal Capacity : 6Ah@0.2C

Energy : 76.8Wh

Internal Resistance : 70≤mΩ

Dimension(L*W*H*TH) : 151*65*94*100mm

Weight : Approx. 1.05Kg

Contact Now

FT-32LFP-12.8V6AH UPS Solar &Wind power system Golf Cart Solar Strret LED Lighting

Features

General Specifications

Electrical Characteristics	Nominal Voltage	12.8V
	Nominal Capacity	6Ah@0.2C
	Energy	76.8Wh
	Internal Resistance	70≤mΩ
	Cycle Life	>2000 Cycles @ 0.2C Charge/Discharge at 100%DOD,End of Life 70% Capacity.
	Months Self Discharge	≤3.5% per month at 25℃
Standard Charge	Charge Voltage	14.6±0.2V
	Charge Mode(CC/CV)	At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C5A, and then,changed continuously with constant voltage of 14.6V until the current was not more than 0.02C5A.
	Charger Current	1.2A
	Max.Charge Current	3A
Standard Discharge	Discharge Current	1.2A
	Max. Continuous Current	6A
	Max.Pulse Current	20A(<3S)
	Disxcharge Cut-off Voltage	10.0V
Environmental	Charge Temperature	0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
	Disxcharge Temperature	-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
	Storage Temperature	0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
	Water Dust Resistance	IP55
Mechanical	Cell & Method	IFR32700 N60,4S1P
	Plastic Case	ABS
	Dimension(LWH*TH)	1516594*100mm
	Weight	Approx. 1.05Kg
	Terminal	F2

76.8Wh Energy Lifepo4 Lithium Ion Battery FT-32LFP-12.8V6AH Free Maintenance
